Dual Socket E2 (LGA-4710) supported, CPU TDP supports Up to 350W TDP
Core
Up to 144 (E) cores
System Memory
Memory Capacity
16 DIMM slots
Up to 2TB ECC Registered RDIMM, DDR5-6400MT/s
Memory Type
6400 MT/s ECC DDR5 Up to 256GB of memory with speeds of up to 8000 MT/s (MRDIMM 1DPC) or 128GB of memory with speeds up to 6400 MT/s (RDIMM 1DPC) or 5200 MT/s (RDIMM 2DPC)
DIMM Sizes
32GB, 64GB, 96GB, 128GB
RDIMM: 32GB, 64GB, 96GB, 128GB
Memory Voltage
1.1V
Error Detection
Corrects single-bit errors
Detects double-bit errors (using ECC memory)
On-Board Devices
Chipset
System on Chip
IPMI
ASPEED AST2600 BMC
Network Controllers
Dual LAN
Dual LAN with Broadcom BCM57416 10GBase-T
Input / Output
SATA
10 SATA3 port(s)
LAN
1 RJ45 Dedicated IPMI LAN port
USB
6 USB 3.1 Gen1 port(s) (2 via header; 4 rear)
Video Output
1 VGA D-Sub Connector port(s)
Serial Port
2 COM Port(s) (1 rear; 1 header)
TPM
1 TPM Header
Others
3 MCIO PCIe 5.0 x8
Expansion Slots
PCIe
2 PCIe 5.0 x8,
4 PCIe 5.0 x16
M.2
M.2 Interface: 2 PCIe 5.0 x4, RAID 0 & 1
Form Factor: 2280/22110
Key: M-Key
System BIOS
BIOS Type
PC Health Monitoring
Voltage
VBAT, System temperature, Memory temperature, CPU temperature, +5V standby, +5V, +3.3V, +12V, CPU thermal trip support, +3.3V standby, Veore, Vmem, Peripheral temperature, Platform Environment Control Interface (PECI)/(TSI)
LED
UID/Remote UID
CPU / System Overheat LED
Temperature
Monitoring for CPU and chassis environment
CPU thermal trip support
Thermal Monitor 2 (TM2) support
PECI
FAN
8x 4-pin fan headers (up to 8 fans)
Fan speed control
Overheat LED indication
8x fans with tachometer monitoring
Other Features
UID
M.2 NGFF connector
Control of power-on for recovery from AC power loss
