Schedule Access| Optional Parts List | |||
| Part Number | Qty | Description | |
| CPU Carrier (Require 4pcs of one PN only) | SKT-1543H-0000-LTS | 4 | Intel GNR-SP Socket E2 LGA4710, E2A XCC carrier, DG 1.0 (Brand LOTES) |
| SKT-1543H-0000-FXC | 4 | Intel GNR-SP Socket E2 LGA4710, E2A XCC carrier, DG 1.0 (Brand FOXCONN) | |
| GPU DW FL Support Kit | SNK-P2091PV-1 | 2 | 1U Passive EVAC CPU Heat Sink for SYS-242H & SYS-242B Server |
| MCP-310-21824-0B | 4 | MEM mylar air shroud for X14 2U 4-way in CS | |
| TBD | 1 | GPU card bracket set for DW full length GPU (Supports 2x DW GPUs) | |
| GPU Power Cable(s) | CBL-PWEX-1040 • |
1/GPU | 8-pin CPU to 8-pin PCIe power connector (Requires 1x CBL-PWEX-1148-20) |
| CBL-PWEX-0962Y-20 | 1/GPU | 16-pin power cable (Example H100) | |
| NVMe Intel VROC Controller | AOC-VROCSTNMOD | 1 | Intel VROC HW key (RSTe) standard upgrade module |
| AOC-VROCPREMOD • |
1 | Intel VROC Premium, RAID 0, 1, 5, 10 | |
| Power Supply | PWS-2K70A-1R • |
1 ~ 4 | 1U 2700W Redundant Titanium w/PMBus power supply, W73.5xH39/40xL203 mm, C20 inlet |
| RAID Controller CacheVault(s) | MCP-240-00203-0N • |
1 | BTR-CVPM05 Supercap mounting bracket for PCIe location (Support up to 2 BTR) |
| BTR-CVPM05 | 1 ~ 2 | CacheVault for Broadcom RAID Controller (Ex. S3908/S3916) | |
| Rail w/ Cable Arm Support Kit | MCP-290-00128-0N | 1 | Gen2 cable arm for Ultra 2U |
| MCP-290-00127-0N | 1 | 39" rail set, quick/quick, 17.2"W, for 2U Gen2 cable arm | |
| SATA3/SAS RAID Controller - 16 Drives | AOC-S3916L-H16IR-32DD | 1 | 16 int 12Gb/s ports, x8 Gen4, ROC - LP |
| CBL-SAST-1281-100 | 2 | Slimline x8 (STR) to 2x Slimline x4 (STR),80CM,100 OHM | |
| SATA3/SAS RAID Controller - 8 Drives | AOC-S3908L-H8IR-16DD | 1 | 8 int 12Gb/s ports, x8 Gen4, ROC - LP |
| CBL-SAST-1281-100 | 1 | Slimline x8 (STR) to 2x Slimline x4 (STR),80CM,100 OHM | |
| TPM Security Module | AOM-TPM-9672V | 1 | TPM 2.0 with 10 pins SPI,RoHS (Vertical) |
| AOM-TPM-9672V-FIPS | 1 | TPM 2.0 with 10 pins SPI support FIPS 140,RoHS (Vertical) | |
| Part Number | SKT-1543H-0000-LTS | SKT-1543H-0000-FXC |
| Qty | 4 | 4 |
| Description | Intel GNR-SP Socket E2 LGA4710, E2A XCC carrier, DG 1.0 (Brand LOTES) | Intel GNR-SP Socket E2 LGA4710, E2A XCC carrier, DG 1.0 (Brand FOXCONN) |
| Part Number | SNK-P2091PV-1 | MCP-310-21824-0B | TBD |
| Qty | 2 | 4 | 1 |
| Description | 1U Passive EVAC CPU Heat Sink for SYS-242H & SYS-242B Server | MEM mylar air shroud for X14 2U 4-way in CS | GPU card bracket set for DW full length GPU (Supports 2x DW GPUs) |
| Part Number | CBL-PWEX-1040 • | CBL-PWEX-0962Y-20 |
| Qty | 1/GPU | 1/GPU |
| Description | 8-pin CPU to 8-pin PCIe power connector (Requires 1x CBL-PWEX-1148-20) | 16-pin power cable (Example H100) |
| Part Number | AOC-VROCSTNMOD | AOC-VROCPREMOD • |
| Qty | 1 | 1 |
| Description | Intel VROC HW key (RSTe) standard upgrade module | Intel VROC Premium, RAID 0, 1, 5, 10 |
| Part Number | PWS-2K70A-1R • |
| Qty | 1 ~ 4 |
| Description | 1U 2700W Redundant Titanium w/PMBus power supply, W73.5xH39/40xL203 mm, C20 inlet |
| Part Number | MCP-240-00203-0N • | BTR-CVPM05 |
| Qty | 1 | 1 ~ 2 |
| Description | BTR-CVPM05 Supercap mounting bracket for PCIe location (Support up to 2 BTR) | CacheVault for Broadcom RAID Controller (Ex. S3908/S3916) |
| Part Number | MCP-290-00128-0N | MCP-290-00127-0N |
| Qty | 1 | 1 |
| Description | Gen2 cable arm for Ultra 2U | 39" rail set, quick/quick, 17.2"W, for 2U Gen2 cable arm |
| Part Number | AOC-S3916L-H16IR-32DD | CBL-SAST-1281-100 |
| Qty | 1 | 2 |
| Description | 16 int 12Gb/s ports, x8 Gen4, ROC - LP | Slimline x8 (STR) to 2x Slimline x4 (STR),80CM,100 OHM |
| Part Number | AOC-S3908L-H8IR-16DD | CBL-SAST-1281-100 |
| Qty | 1 | 1 |
| Description | 8 int 12Gb/s ports, x8 Gen4, ROC - LP | Slimline x8 (STR) to 2x Slimline x4 (STR),80CM,100 OHM |
| Part Number | AOM-TPM-9672V | AOM-TPM-9672V-FIPS |
| Qty | 1 | 1 |
| Description | TPM 2.0 with 10 pins SPI,RoHS (Vertical) | TPM 2.0 with 10 pins SPI support FIPS 140,RoHS (Vertical) |
