Supermicro® Microsoft® Certified Solutions

Supermicro and Microsoft have partnered together to deliver industry leading "fully certified solutions". These solutions are delivered on highly optimized and flexible Supermicro Server and Storage Systems. Supermicro Systems are designed to provide significant advantage to these solutions in the areas of power efficiency, performance and overall system optimization. These design principles coupled with bringing innovative technologies at an accelerated pace drives time to market value for Microsoft Solutions. In case of some of these disruptive technologies like NVMe, Supermicro is an established leader with the broadest range of products that customers can choose from.

Microsoft Certified Solutions running on Supermicro hardware consist of Windows Server, SQL Server Data Warehouse, Exchange Server, Hyper-converged solutions like Storage Spaces Direct, Storage Server and Azure Stack. These solutions are optimized for Enterprise, Hybrid Cloud, Private and Public Cloud markets. We also deliver the Windows operating system software preloaded for fast growing SMB and Enterprise customers.

Supermicro has consistently innovated in the areas of designing Server board, Chassis, highly efficient power supply, network interconnect and storage systems. The building block approach is one of the key innovations to Server system architecture. This vertically integrated design approach accelerates the delivery of application optimized Microsoft Solutions based on customer requirements.

Data Warehouse Fast Track For Microsoft® SQL Server®

Microsoft Data Warehouse Fast Track (DWFT) for SQL Server® 2016 is designed to provide customers optimized and validated system architectures for addressing data warehouse workload challenges including exponential growth of data, demands of lower data latency and faster query response times.

Supermicro has partnered with Microsoft to deliver Industry's highest performance 70TB SQL Server 2016 DWFT reference architecture in 2 socket systems, leveraging highly efficient Ultra Servers utilizing low latency and high throughput NVMe SSD's.

Data Warehouse Fast Track Comparison Chart
 70TB DWFT40TB DWFT22TB DWFT
Model
Supermicro Data Warehouse Fast Track 70TB DWFT SYS-2028U-TN24R4T+
SYS-2028U-TN24R4T+
SMCI DP
Supermicro Data Warehouse Fast Track 40TB DWFT SYS-2028U-TN24R4T+
SYS-2028U-TN24R4T+
SMCI DP
Supermicro Data Warehouse Fast Track 22TB DWFT SYS-2028U-TNR4T+
SYS-2028U-TNR4T+
SMCI DP
CPUIntel Xeon E5-2690 v4 2.60GHz 135W 14 core x2Intel Xeon E5-2690 v4 2.60GHz 135W 14 core x2Intel Xeon E5-2690 v4 2.60GHz 135W 14 core x2
Memory32GB DDR4-2133 x24 = 768GB32GB DDR4-2133 x24 = 768GB32GB DDR4-2133 x24 = 768GB
Data storage2.5" NVMe
3.2TB x 10 = 32TB
2.5" NVMe P3700 800GB x8
2.5" NVMe P3600 2TB x 4 = 14.4TB
2.5" NVMe P3600
2TB x 4 = 8TB
Log2TB SAS3 SSD 2.5" x4
(Raid 10)
2TB SAS3 SSD 2.5" x4
(Raid 10)
300GB 12G SAS3 HD 15k 2.5" x8 (Raid 10)
OS400GB SATA3 SSD x2 (Raid 1)480GB SATA3 SSD x2 (Raid 1)480GB SATA3 SSD x2 (Raid 1)
Storage AOCS3108L-H8iR (HW raid)S3108L-H8iR (HW raid)S3108L-H8iR (HW raid)
Performance
Rated User Data Capacity (TB)704022
Row Store relative Throughput225210166
Column Store relative Throughput339213196
Maximum User Data Capacity (TB)1034825
Row Store
Relative Throughput225210166
Measured Throughput (Queries/Hr/TB)274244202
Measured Scan Rate Physical (MB/Sec)582055714348
Measured Scan Rate Logical (MB/Sec)740967905436
Measured I/O Throughput (MB/Sec)661461804892
