Generation
Others
# of CPU Sockets
Single
CPU Type Supported
- Intel® Atom® Processor C3958
- Single Socket FCBGA-1310 supported, CPU TDP support Up to 31W TDP
Memory Capacity
- Up to 256GB ECC RDIMM, DDR4 -2400MHz, Up to 64GB Unbuffered ECC/non-ECC UDIMM, DDR4 -2400MHz, in4 DIMM slots
Memory Type
- 2400/2133/1866/1600MHz ECC/non-ECC DDR4 Unbuffered UDIMM, RDIMM and /
Form Factor
Mini-ITX 6.7" x 6.7"
Chipset
System on Chip
# of System Memory Slots
4
Onboard Storage Controller
- SoC controller for 12 SATA3 (6 Gbps) ports; RAID
Expansion Slot
- 1 PCI-E 3.0 x4
- M.2 Interface: SATA and PCI-E 3.0 x2
- M.2 Form Factor: 2280, 2242
- M.2 Key: M-Key
Onboard LAN
Quad LAN with Intel® C3000 SoC 2 10GBaseT and 2 10Gb SFP+
USB
- 4 USB 2.0 ports (2 via headers + 2 rear)
- 1 USB 3.2 Gen1 ports (1 type A)
Video Output
1 VGA port
Other Onboard I/O Devices
- 1 COM Port (1 header)
TPM Header
Yes
Storage Interfaces
- 12 SATA3 (6Gbps) ports
- M.2 Interface: SATA and PCI-E 3.0 x2
- M.2 Form Factor: 2280, 2242
- M.2 Key: M-Key
