Standard Parts List | |||
Part Number | Qty | Description | |
Air Shroud | MCP-310-49004-0N | 1 | SC847/417 DP X9 universal PC air shroud 1368x13/12x13MB |
HD Backplane | BPN-SAS3-216EL1 | 3 | 24-port 2U SAS3 12Gbps single-expander backplane, support up to 24x 2.5-inch SAS3/SATA3 HDD/SSD |
Cable(s) | CBL-0071L | 1 | ROUND 16 TO 16 PIN RIBBON FP CABLE 30"L, LF |
Cable(s) | CBL-0160L | 2 | US POWER CORD 16AWG, PB FREE |
Cable(s) | CBL-0217L | 1 | 16PIN CNTL PANEL CONVERTER CBL FOR SC826,PBF |
Fan(s) | FAN-0126L4 | 7 | 80x80x38 mm 7K RPM Chassis Middle Fan w/ Housing |
Front Panel | MCP-280-82601-0N | 1 | Front control board adapter (TB826) for SC216,826,936,846 |
Drive Tray(s) | MCP-220-00047-0B | 72 | Black gen 3rd hot-swap 2.5inch HDD tray |
Drive Tray(s) | MCP-220-84708-ASM | 1 | SC847B LP MB Tray assembly,HF,RoHS/REACH |
Mounting Rail(s) | MCP-290-00057-0N | 1 set | Rail set, quick/quick, default for 4U 17.2"; W |
Optional Parts List | |||
Part Number | Qty | Description | |
HDD Kit | MCP-220-82609-0N | - | Optional rear 2.5" HDD kit for 826BA/E16/E26 only |
Drive Trays | MCP-220-84701-0N | - | Internal drive bay for one 3.5" HDD or two 2.5" HDD |
Front Bezel | MCP-210-84601-0B | - | Front Bezel Cover, Black with Key Lock |
Rail | MCP-290-00061-0N | - | Non-threaded rail adapter optional for round thread rack |
HDD Kit | MCP-220-82616-0N | - | 12G 2.5x2 Drive Kit w/ Status LED (216B/826B/417B/846X/847B |
