Standard Parts List | |||
Part Number | Qty | Description | |
HD Backplane | BPN-SAS3-743A | 1 | 8-port 4U/Tower 3.5-inch SAS3/SAS2/SATA3 12Gbps backplane for SC743/SC745 chassis |
Cable(s) | CBL-SAST-0631 | 2 | Cross-over Mini SAS HD to 4 SATA w/SB, S. 55cm. 30AWG |
Optional Parts List | |||
Part Number | Qty | Description | |
Mounting Rail | CSE-PT26L-(B) | - | |
Cable | CBL-0157L | - | 8 pin to 8 pin ribbon SGPIO cable with tube , 40cm, PBF |
Cable | CBL-0454L | - | USB 3.0 to 2.0 Adapter Cable 30cm (19 pin Male to 9 pin Female). 28/24AWG |
Heatsink / Retention | - | - | Please refer to our Thermal Components Matrix |
Peripheral Drive(s) | DVM-LITE-DVDRW24-HBT | - | BLACK LITE-ON 5.25" HH 24X DVD-RW SATA DRIVE PBF |
HDD Tray | MCP-220-00080-0B | - | Black hotswap gen 2 3.5 to 2.5 HDD tray |
Motherboard (for CSE- 743AC-1200B-SQ) | ||||
X11SSH-F | X11SSH-LN4F | X11SSZ-TLN4F | X11SSZ-F | |
X11SSZ-QF | X11SAE | X11SAE-F | X11SAE-M | |
X11DAi-N | X11SRA | X11SRA-F | X11SRA-RF | |
X11DAC | X11SCZ-F | X11SCZ-Q | X11SPA-TF | |
X11SPA-T | X11SSL-F | X11SSL-CF | X11SSL-nF | |
X11SSL | X11SSM-F | X11SSM | X11SSH-CTF | |
X11SSH-TF | ||||
= Most optimized Chassis for SuperServer Configuration Blue color = Compatible Green color = Global SKU & Compatible Red dot & green color = Optimized + Global SKU |
Servers (for CSE- 743AC-1200B-SQ) | ||||
5049A-T | ||||
