 | | PCI-E | | | | | | BIOS Type | | | | | | Software | - IPMI2.0, KVM with dedicated LAN, NMI, SuperDoctor® 5, Watchdog
| | Power Configurations | - +12V DC Power Input
- ATX Power connector
- ACPI Power Management
- Control of power-on for recovery from AC power loss
| | | | | Voltage | - +1.8V, +12V, +3.3V, +5V, +5V standby, Chassis intrusion header, Supports system management utility, System level control
| | FAN | - 3x 4-pin fan headers (up to 3 fans), Fan speed control, Overheat LED indication, PWM fan speed control, System level control, Thermal control tachometer fan connectors
| | Temperature | - CPU thermal trip support, Thermal Control for 3 Fan Connectors
| | LED | - Power LED, CPU / System Overheat LED, BMC/IPMI Heartbeat LED, UID/Remote UID
| | Other Features | - 12V DC or ATX Power Source, 4-pin 12v DC power connector, ACPI power management, ATX Power connector, Chassis intrusion header, Control of power-on for recovery from AC power loss, CPU thermal trip support for processor protection, RoHS, System level control, UID, WOL
| | |  | | Operating Temperature Range | - 0°C ~ 60°C (32°F ~ 140°F)
| | Non-Operating Temperature Range | - -40°C - 85°C (-40°F - 185°F)
| | Operating Relative Humidity Range | - 10% ~ 85% (non-condensing)
| | Non-Operating Relative Humidity Range | - 10% ~ 95% (non-condensing)
| |
SC504-203B
SC505-203B
= Most optimized Chassis for SuperServer Configuration
