In the era of AI, a unit of compute is no longer measured by just the number of servers. Interconnected GPUs, CPUs, memory, storage, and these resources across multiple nodes in racks construct today's artificial intelligence. The infrastructure requires high-speed and low-latency network fabrics, and carefully designed cooling technologies and power delivery to sustain optimal performance and efficiency for each data center environment. Supermicro’s SuperCluster solution provides end-to-end AI data center solutions for rapidly evolving Generative AI and Large Language Models (LLMs).
Complete Integration at Scale
Design and build of full racks and clusters with a global manufacturing capacity of up to 5,000 racks per month
Test, Validate, Deploy with On-site Service
Proven L11, L12 testing processes thoroughly validate the operational effectiveness and efficiency before shipping
Liquid Cooling/Air Cooling
Fully integrated liquid-cooling or air cooling solution with GPU & CPU cold plates, Cooling Distribution Units and Manifolds
Supply and Inventory Management
One-stop-shop to deliver fully integrated racks fast and on-time to reduce time-to-solution for rapid deployment
The full turn-key data center solution accelerates time-to-delivery for mission-critical enterprise use cases, and eliminates the complexity of building a large cluster, which previously was achievable only through the intensive design tuning and time-consuming optimization of supercomputing.
Liquid-Cooled NVIDIA HGX B200 AI Cluster
With up to 32 NVIDIA HGX B200 8-GPU, 4U Liquid-cooled Systems (256 GPUs) in 5 Racks
- Deploy the pinnacle of AI training and inference performance with 256 NVIDIA B200 GPUs in one scalable unit (5 racks)
- Supermicro Direct Liquid Cooling featuring 250kW capacity in-rack Coolant Distribution Unit (CDU) with redundant PSU and dual hot-swap pumps
- 45 TB of HBM3e memory in one scalable unit
- Scale-out with 400Gb/s NVIDIA Spectrum™-X Ethernet or NVIDIA Quantum-2 InfiniBand
- Customizable data storage fabric with industry leading parallel file system options
- Support for NVIDIA AI Enterprise Platform including NVIDIA NIM microservices
Compute Node
Air-Cooled NVIDIA HGX B200 AI Cluster
With 32 NVIDIA HGX B200 8-GPU, 10U Air-cooled Systems (256 GPUs) in 9 Racks
- Proven industry leading architecture with new thermally-optimized air-cooled system platform
- 45 TB of HBM3e memory in one scalable unit
- Scale-out with 400Gb/s NVIDIA Spectrum-X Ethernet or NVIDIA Quantum-2 InfiniBand
- Customizable data storage fabric with industry leading parallel file system options
- Support for NVIDIA AI Enterprise Platform including NVIDIA NIM microservices
Compute Node
NVIDIA GB200 NVL72
Liquid-cooled Exascale Compute in a Single Rack
- 72x NVIDIA Blackwell B200 GPUs acting as one GPU with a massive pool of HBM3e memory (13.5TB per rack)
- 9x NVLink Switch, 4 ports per compute tray connecting 72 GPUs to provide 1.8TB/s GPU-to-GPU interconnect
- Supermicro Direct Liquid Cooling featuring 250kW capacity in-rack Coolant Distribution Unit (CDU) with redundant PSU and dual hot-swap pumps
- Supermicro’s end-to-end liquid-cooling solution and comprehensive onsite deployment services
- Ready for advanced networking technologies for scaling including NVIDIA BlueField®-3 SuperNIC, Spectrum-X, Quantum-2, and next generation 800 Gb/s networking platforms
Compute Tray
- ARS-121GL-NBO-LCC
(not sold individually)
Leading Liquid-Cooled AI Cluster
With 32 NVIDIA HGX H100/H200 8-GPU, 4U Liquid-cooled Systems (256 GPUs) in 5 Racks
- Doubling compute density through Supermicro’s custom liquid-cooling solution with up to 40% reduction in electricity cost for data center
- 256 NVIDIA H100/H200 GPUs in one scalable unit
- 20TB of HBM3 with H100 or 36TB of HBM3e with H200 in one scalable unit
- 1:1 networking to each GPU to enable NVIDIA GPUDirect RDMA and Storage for training large language model with up to trillions of parameters
- Customizable AI data pipeline storage fabric with industry leading parallel file system options
- Supports NVIDIA Quantum-2 InfiniBand and Spectrum-X Ethernet platform
- Certified for NVIDIA AI Enterprise Platform including NVIDIA NIM microservices
Compute Node
Proven Design
With 32 NVIDIA HGX H100/H200 8-GPU, 8U Air-cooled Systems (256 GPUs) in 9 Racks
- Proven industry leading architecture for large scale AI infrastructure deployments
- 256 NVIDIA H100/H200 GPUs in one scalable unit
- 20TB of HBM3 with H100 or 36TB of HBM3e with H200 in one scalable unit
- 1:1 networking to each GPU to enable NVIDIA GPUDirect RDMA and Storage for training large language model with up to trillions of parameters
- Customizable AI data pipeline storage fabric with industry leading parallel file system options
- Supports NVIDIA Quantum-2 InfiniBand and Spectrum-X Ethernet platform
- Certified for NVIDIA AI Enterprise Platform including NVIDIA NIM microservices
Compute Node
